Mining Dump Truck Technical Specifications:
|
1.Shanghai Longji Construction Machinery Co., Ltd.
|
|
2.Vehicle Type
|
Mining Dump Truck
|
3.Trade-mark(Brand)
|
Hualing Star
|
|
4.Vehicle Model
|
HN3250P34C6M
|
5.Color
|
Yellow
|
|
6.Engine Brand
|
DF Cummins
|
7.Engine Model
|
L375 20
|
|
8.Fuel Type
|
Diesel Oil
|
9.Displacement Standard
|
GB3847-2004
GB17691-2001
|
|
10.Displacement/ power(ml/kw)
|
8900/273
|
11.Emission Standard
|
Euro II
|
|
12.Steering
|
steering Wheel
|
13.Driving Model
|
Left-hand
|
|
14.Transmission Type
|
9JS150T
|
15.Transmission Brand
|
FAST GEAR
|
|
16.Tread(mm)
|
2065/1860/1860
|
17.Tire Number
|
10+1
|
|
18.Tire Specification
|
12R22.5(tubeless)
|
19.Number of Plate Spring(F/R)
|
9/12
|
|
20.Wheel Bas(mm)
|
3600+1350
|
21.Number of Axle
|
3
|
|
22.Overall Dimensio(L×W×H)(mm)
|
8080×2495×3200
|
23.Packing Box Inside Dimension(L×W×H)(mm)
|
5400×2300×1500
|
|
24.GVW(kg)
|
25000
|
25.Rated Payload (kg)
|
12455
|
|
26.Kerb Mass(kg)
|
12350
|
27.Ratio of Payload and Kerb Mass
|
1.02
|
|
28.Crew
|
3
|
29.Mini. Ground Clearance
|
255mm
|
|
30.Max. Speed(km/h)
|
75
|
31.Date of Production
|
the Update
|
|
Remarks
|
Including air conditioner,Mp3 player, Hitachi steering device.
We can produce the truck you need according to your special requirement.
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Different outfits are provided for the different configurations of the motor vehicles.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual motor vehicles.
& CAMC reserves the rights to make final explanations.
